EVD/EVD-W
The light weight deflectometer (LWD) is a hand portable device to measure the soil in situ dynamic modulus which is used to evaluate the subsoil degree of compaction.
It is suitable for the construction quality monitoring and testing of railway, highway, airport and indus-trial buildings under dynamic load, and especially suitable for the detec-tion of narrow sections of the site, such as transition sections of roads and bridges, backfilling of pipeline and cable, etc.
The light weight deflectometer (LWD) is a hand portable device to measure the soil in situ dynamic modulus which is used to evaluate the subsoil degree of compaction.
It is suitable for the construction quality monitoring and testing of railway, highway, airport and indus-trial buildings under dynamic load, and especially suitable for the detec-tion of narrow sections of the site, such as transition sections of roads and bridges, backfilling of pipeline and cable, etc.
Features
1.Easy to carry and easy to operate.
2.Fast and cost-saving: only 35 seconds per measuring point.
3.CalculateEvd valueautomatically, and display the curve.
4.Wireless Bluetooth micro printer, print test results on site.
5.Testing can be achieved in difficult to reach locations.
6.It can be connected to the engineering test managementsystem, providing reliable data sources for online dataanalysis and big data management.
TECHNICAL PARAMETERS
EVD
Soil type: Various types of soil, earth and stone mixed fillers with a particle size not larger than 1/4 of the diameter of the load plate
Measuring range: 10Mpa~225Mpa
Testing depth 0~500mm
Working condition Temperature: -10℃~40℃ Humidity: ＜90%RH
Loading device: Weight: 15kg, drop hammer weight: 10kg, free fall height: 700±20mm, Max. impact force: 7.07kN, Impact duration: 18±1ms
Load plate Weight: 15kg Diameter: 300mm Thickness: 20mm
Deflection measuring range 0.10mm~2.00mm
Storage capacity: 2000 groups
Measuring instrument specifications: Screen size: 3 inch Weight: 0.8kg, Monitor dimension: 100x205x40mm
Power supply: Lithium battery, working time is greater than 18 hrs.
Printer connection method: Wireless bluetooth printing
Main frame: Material: engineering plastic Diemsnion: 420x140x335mm Weight: 4.5kg
Overall packing: Material: aluminum alloy Dimension: 1220x395x380mm Weight: 56kg
EVD-W
Soil type: Various types of soil, earth and stone mixed fillers with a particle size not larger than 1/4 of the diameter of the load plate
Measuring range: 10Mpa~225Mpa
Testing depth 0~500mm
Working condition Temperature: -10℃~40℃ Humidity: ＜90%RH
Loading device: Weight: 15kg, drop hammer weight: 10kg, free fall height: 700±20mm, Max. impact force: 7.07kN, Impact duration: 18±1ms
Load plate Weight: 15kg Diameter: 300mm Thickness: 20mm
Deflection measuring range 0.10mm~2.00mm
Storage capacity: Depending on Mobile's memory
Measuring instrument specifications: Screen size: 5 inch Weight: 110g, Monitor dimension: 145x70x10mm
Power supply: Depending on Mobile's battery
Printer connection method: Wireless bluetooth printing
Main frame: Material: engineering plastic Diemsnion: 420x140x335mm Weight: 4.5kg
Overall packing: Material: aluminum alloy Dimension: 1220x395x380mm Weight: 56kg
