54-C0147
V-Funnel apparatus is used to evaluate the segregation resistance of freshly mixed self-compacting concrete by the observation on the flowing speed due to the difference of samples remaining period in the funnel. It consists of a funnel placed vertically on a supporting stand, having 10 litres capacity, stand mounted.
STANDARD
- EN 12350-9
Get Wholesale Price
This apparatus is used to evaluate the segregation resistance of freshly mixed self-compacting concrete by the observation on the flowing speed due to the difference of samples remaining period in the funnel. It consists of a funnel placed vertically on a supporting stand, having 10 litres capacity, stand mounted.
The upper edge of the funnel is smooth and reinforced, and the outflow orifice is equipped of an openable seal valve.
Funnel (width x deep): 515 x 75 mm
Height over all: 1000 mm
Weight approx: 20 kg
