TPBM-A750
The Böhme Abrasion Tester TPBM-A750 is mainly used for carrying out abrasive resistance test on natural stone and other constructive materials (such as artificial stone, glass ceramics, construction brick etc.).
The test is performed by positioning a specimen to be verified on the test track of the Böhme abrasion tester. The grinding wheel is made rotate and the specimen submitted to the abrasive load of 294N±3N for a certain number of cycles.
STANDARD
- EN14157
Get Wholesale Price
The Böhme Abrasion Tester TPBM-A750 is mainly used for carrying out abrasive resistance test on natural stone and other constructive materials (such as artificial stone, glass ceramics, construction brick etc.).
The test is performed by positioning a specimen to be verified on the test track of the Böhme abrasion tester. The grinding wheel is made rotate and the specimen submitted to the abrasive load of 294N±3N for a certain number of cycles.
TECHNICAL PARAMETERS
Grinding wheel diameter: Ø750mm
Grinding wheel stiffness: 190HB~220HB
Grinding wheel rotate speed: (30±1)r/min
Test track diameter: Ø220mm
Abrasive load on specimen: 294N±3N
Revolution counter range: 0~9999
Specimen size: (71±1.5)mm×(71±1.5)mm
Power supply: Three-phase four-wire 380V 50Hz
Power: 0.55kW
Dimensions: 830mm(L)×1070mm(W)×800mm(H)
Weight: Approximately 160kg
