33-T007 series

Proctor mould
Proctor mould is used for determining the relationship between the moisture content and density of compacted soil. Made of plated steel. Includes collar, mould body and base plate. Different models are available conforming to the various specifications in use. They are identical in shape and slightly differ in diameter and capacity.
Different models are available conforming to the various specifications in use. They are identical in shape and slightly differ in diameter and capacity.

ASTM models
33-T0070  Int. dia.101.6mm  Body height116.4mm  7kg
33-T0071  Int. dia.152.4mm  Body height116.4mm  9kg
33-T0073  Int. dia.152.4mm  Body height116.4mm  9.5kg

EN models
33-T0070/E  Int. dia.100 ± 1mm  Body height120 ± 1mm  5kg
33-T0071/E  Int. dia.150 ± 1mm  Body height120 ± 1mm  8.9kg

Proctor rammer
Proctor rammer is used to compact the soil sample in the Proctor moulds. Made of plated steel. Guide sleeve with vent holes. Different models are available conforming to the various specifications in use.

ASTM models
33-T0075  Rammer dia.50.8mm  Free fall height305mm  3kg
33-T0076  Rammer dia.50.8mm  Free fall height457.2mm  5.3kg

EN models
33-T0075  Rammer dia.50.0 ± 0.05mm  Free fall height305 ± 3mm  3.6kg
33-T0076  Rammer dia.50.0 ± 0.05mm  Free fall height457 ± 3mm  6.3kg
