TP-602
The concrete thickness tester is designed for thickness measurement of floor slabs or walls, beams, columns, wood, ceramics and other non-ferromagnetic media. It has functions such as thickness measurement, data analysis, data storage and output. It is an intelligent device that is portable, easy to use and accurate in measurement.
The concrete thickness tester is designed for thickness measurement of floor slabs or walls, beams, columns, wood, ceramics and other non-ferromagnetic media. It has functions such as thickness measurement, data analysis, data storage and output. It is an intelligent device that is portable, easy to use and accurate in measurement.
FEATURES
· Full-color LCD screen and silicone dust-proof buttons make on-site operation more comfortable;
· Using the new ARM high-speed acquisition system, the test speed is faster;
· The receiving probe automatically determines the direction and locks the center range, greatly improving detection efficiency;
· The host and the receiving probe are connected via Bluetooth signals to avoid signal line failures affecting the test, and also make standing inspection easier;
· The test thickness is displayed in real time and the minimum value is automatically locked to prevent misjudgment;
· Data setting and review are more intuitive, and parameters such as average value, pass rate, etc. can be viewed at will;
· Calibration function. The accuracy can be calibrated during use to make the detection results more accurate;
· Brightness adjustment. The level of backlight brightness can be selected according to the lighting level of the external environment, and eight levels are adjustable;
· Topic selection. Improves screen visibility under outdoor lighting
TECHNICAL PARAMETERS
Thickness measurement range: 40-1000mm
Test accuracy: 40-400mm: ±1mm / 401-800mm: ±2mm / 801-1000mm: ±3mm
Data storage: 2 million measurement data
Display: Color LCD display, resolution 480x800, adjustable display brightness
Data transmission: USB
Software: Can run under WinXP, Win7, Win8, Win10 and other systems
Working environment: Ambient temperature: -10℃~ +50℃, avoid direct sunlight exposure for a long time; Relative humidity: ≤90%RH; Electromagnetic interference: no strong alternating electromagnetic field
Power supply: Built-in rechargeable lithium battery, power supply time up to 8 hours
Host dimensions: 219×56×139mm
